Small Walkway Corner Tent
The small walkway corner tent is a compact connector that joins separate marquee bays and turns tight angles into sheltered, weatherproof passages. It keeps guests dry between halls, stages, and catering areas.
Our small walkway corner tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Bridge two tent modules at 90° or custom angles with a 3–6 m wide covered walkway.
- Reuse the same hard-pressed aluminum profile as your main halls for one consistent frame system.
- Fit gable, curved, or pagoda roof styles to match the connected structures.
- Add transparent sidewalls so the link stays bright and open-feeling.
- Install cable channels and lighting along the eaves for safe night passage.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 3–6 m walkway width (10–20 ft), customizable corner |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Connecting wedding ceremony and banquet marquees.
- Linking exhibition halls to registration and catering tents.
- Sheltered routes between hospital and emergency triage tents.
- Rain-free walkways at festivals and campus events.
Related Products
Small Walkway Corner Tent — Frequently Asked Questions
What span widths are available for the small walkway corner tent?
Clear spans from 3 m up to 3–6 m walkway width (10–20 ft), customizable corner are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the small walkway corner tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
