The roll up catering tent turns any open side into a service window, letting crews serve food and drinks straight from a sheltered prep line.
Our roll up catering tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Roll side curtains up to full headroom for fast service and clear sightlines.
- Span 4–15 m on a lightweight aluminum frame that sets up in under an hour.
- Fit stainless counters, sinks and pass-through hatches along the open bays.
- Seal the PVC walls for hygiene-rated food-prep enclosures.
- Pack the whole unit into wheeled cases for daily mobile catering.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 4–15 m width, 2.5–4 m eave |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Outdoor food festivals and street-food markets
- Wedding and corporate buffet stations
- Construction-site and event mess halls
- Pop-up bars and coffee kiosks
Related Products
Roll Up Catering Tent — Frequently Asked Questions
What span widths are available for the roll up catering tent?
Clear spans from 3 m up to 4–15 m width, 2.5–4 m eave are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the roll up catering tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
