The arcum tent combines a clear-span aluminum frame with a curved, wave-shaped roof for a softer, more architectural silhouette than a standard A-frame. It is a favorite for upscale events, brand activations and venues that want a distinctive profile.
Product Overview
- Curved wave roof for a distinctive architectural look
- Clear-span aluminum frame, no interior poles
- Mix with straight bays to shape atriums and aisles
- Glass and solid wall options
- Reusable for touring and permanent sites
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–40 m (33–131 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Upscale private events
- Brand activations and launches
- Hotels and venue additions
- Exhibitions and galas
Related Products
Arcum Tent — Frequently Asked Questions
What span widths are available for the arcum tent?
Clear spans from 3 m up to large widths are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the arcum tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
Send the site details, required size and operating season for a tailored specification.
How to Choose the Right Arcum Tent
When sourcing a Arcum Tent for your site, compare the main options before you buy:
| Option | Best for | Key note |
|---|---|---|
| This Arcum Tent | elegant curved clear-span halls | Column-free aluminum clear span, customizable walls |
| Warehouse Tent | storage, logistics & temporary warehouses | Part of our clear-span tent range |
| Stretch Tent | flexible outdoor events & branding | Part of our clear-span tent range |
| Gym Tent | sports, training & recreation halls | Part of our clear-span tent range |
Explore related models for your layout: Warehouse Tent Stretch Tent Gym Tent Crown Tent Mini Pagoda Tent. Our team confirms span, eave height, and wall system to match your site and wind load.
Arcum Tent Product Decision Path
Compare this curved-roof structure with the wider event tent product range, review clear span event tent planning, and use the commercial buying guide before preparing an RFQ.
