Indoor go-kart racing venues give operators an all-weather track hall with the clearance, flooring and lighting a kart circuit demands.
Our indoor go kart racing venue uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Span 20–50 m clear for tight corners, pit lanes and spectator rafts.
- Build a resin or asphalt-ready sub-floor rated for kart loads.
- Hang timing, CCTV and track-light truss from the ridge beam.
- Rate structure to 120 km/h wind for semi-exposed sites.
- Seal PVC walls for exhaust control and indoor air comfort.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 20–50 m width, 4–8 m eave |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 120 km/h (75 mph), 0.6 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Commercial karting centres and family tracks
- Corporate team-building arenas
- Rental fleet indoor showrooms
- Junior and electric kart academies
Related Products
Indoor Go Kart Racing Venue — Frequently Asked Questions
What span widths are available for the indoor go kart racing venue?
Clear spans from 3 m up to 20–50 m width, 4–8 m eave are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the indoor go kart racing venue be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
