Push Pull Warehouse Tent
The push-pull warehouse tent is a modular aluminum shelter with an electric retractable roof that opens the bay to open sky or closes it for a sealed store. One button switches between indoor and outdoor mode for loading, storage and work.
Our push pull warehouse tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Reach up to 45 m clear span on a modular aluminum frame with no welding on site.
- Open and close the roof by one-button electric control for indoor or outdoor use.
- Fit sliding glass wall panels that vent the space when the roof is closed.
- Run the overhead steel track so the roof moves smoothly and quietly.
- Assemble, dismantle and recycle the kit fast for temporary or rotating sites.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10-45 m span (33-148 ft), electric retractable roof |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Bulk material and equipment storage.
- Loading and dispatch bays.
- Vehicle and machinery workshops.
- Seasonal and event-site warehouses.
Related Products
Push Pull Warehouse Tent — Frequently Asked Questions
What span widths are available for the push pull warehouse tent?
Clear spans from 3 m up to 10-45 m span (33-148 ft), electric retractable roof are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the push pull warehouse tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
