Hexagon Tent
The Hexagon Tent delivers a striking six-sided clear-span shelter built on a hard-pressed aluminum frame, ideal when a round footprint outperforms a standard rectangle.
Our hexagon tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Erect a 10-40 m diameter hexagon on a single anodized 6061/T6 aluminum frame with no center poles.
- Cover the structure with 850 g/m2 UV-resistant PVC roof and 650 g/m2 sidewalls.
- Choose blackout, translucent, or glass wall options for daylight control.
- Hold 80-100 km/h wind and 75 kg/m2 snow via galvanized steel connectors.
- Add HVAC, lining, and a solid or glass entrance to suit the venue.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | Diameter 10-40 m (33-131 ft), eave height 3-5 m |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Wedding ceremonies and anniversary banquets.
- Trade-show feature spaces and VIP lounges.
- Community civic events and town festivals.
- Seasonal garden restaurants and cafes.
Related Products
Hexagon Tent — Frequently Asked Questions
What span widths are available for the hexagon tent?
Clear spans from 3 m up to Diameter 10-40 m (33-131 ft), eave height 3-5 m are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the hexagon tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
