Arcum Aluminum Orangery
The Arcum aluminum orangery pairs a curved clear-span roof with solid insulated aluminum walls, giving you a bright conservatory-style space that reads like permanent architecture.
Our arcum aluminum orangery uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Span 10–30 m with a curved arcum profile that sheds rain and snow without interior poles.
- Build walls from 4 mm anodized aluminum glazing or 650 g/m² PVC sidewalls to switch from conservatory to event hall.
- Reach eave heights of 3–5 m and ridge clears of up to 7 m for tall planting or staging.
- Join bays in 3–5 m modules so the footprint grows with your garden or venue.
- Carry wind loads of 80–100 km/h and snow of 75 kg/m² with galvanized steel connectors.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–30 m width (33–98 ft), eave height 3–5 m |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Garden conservatories and backyard orangery rooms
- Upscale garden weddings and private dining
- Vineyard tastings and estate open days
- Year-round nursery and plant display houses
Related Products
Arcum Aluminum Orangery — Frequently Asked Questions
What span widths are available for the arcum aluminum orangery?
Clear spans from 3 m up to 10–30 m width (33–98 ft), eave height 3–5 m are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the arcum aluminum orangery be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
