Hexadome Tent
The hexadome tent is a hexagonal-based geodesic shelter that combines the strength of triangulation with a distinctive six-sided plan. It tiles neatly into honeycomb clusters for large-scale camps and villages.
Our hexadome tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Assemble a hexagonal geodesic frame from 8 m to 30 m across flat sides with no interior poles.
- Triangulate walls and roof in aluminum for stable wind and snow performance.
- Clad flat faces in PVC, glass, or hybrid panels with operable vents.
- Tessellate multiple hexadomes into connected honeycomb layouts.
- Fit each face with doors or windows to direct flow between pods.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 8–30 m diameter (26–98 ft), hexagonal base |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Festival glamping and eco-resort villages.
- Modular classroom and training clusters.
- Exhibition pavilions arranged as a campus.
- Emergency housing and field stations.
Related Products
Hexadome Tent — Frequently Asked Questions
What span widths are available for the hexadome tent?
Clear spans from 3 m up to 8–30 m diameter (26–98 ft), hexagonal base are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the hexadome tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
