The panorama dome is a geodesic shelter built for uninterrupted views, with full-perimeter glazing and a clean clear-span interior. It turns a viewpoint, terrace, or plaza into an all-weather observation space.
Our panorama dome uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Erect a geodesic aluminum frame from 8 m to 30 m across with no interior columns.
- Glaze the full perimeter in tempered glass with opening panels for airflow.
- Specify tinted, Low-E, or clear glass to manage heat and glare.
- Crown the apex with a vented oculus for passive ventilation.
- Add a solid or glass entrance module and link to adjacent marquees.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 8–30 m diameter (26–98 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Scenic restaurants and sky-lounges.
- Observation decks and visitor centers.
- Garden wedding and reception venues.
- Showrooms needing bright, open display floors.
Related Products
Panorama Dome — Frequently Asked Questions
What span widths are available for the panorama dome?
Clear spans from 3 m up to 8–30 m diameter (26–98 ft) are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the panorama dome be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
