Octagonal Tent
The octagonal tent is an eight-sided clear-span structure that turns a standard footprint into a striking focal point for events, dining and display. Its aluminum frame holds a peaked or diamond roof with no interior poles, keeping the full floor open.
Our octagonal tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Span 8-30 m across flat-to-flat faces with modular bays extending length on 3-5 m spacing.
- Build the frame from anodized 6061/T6 aluminum with hot-dip galvanized steel connectors for corrosion resistance.
- Dress the roof and walls in 850 g/m2 PVC covers that are UV-stable, waterproof and flame retardant to B1.
- Configure glass walls, clear PVC panels, lining or hard flooring to match the venue and season.
- Rate the structure for 80-100 km/h wind and 75 kg/m2 snow, so it stands through changing weather.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 8-30 m side-to-side (26-98 ft), eave height 2.5-4 m |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Wedding ceremonies and anniversary banquets needing a shaped centerpiece.
- Product launches and brand exhibitions on the show floor.
- Restaurant and cafe garden dining under cover.
- Festival and community gathering spaces.
Related Products
Octagonal Tent — Frequently Asked Questions
What span widths are available for the octagonal tent?
Clear spans from 3 m up to 8-30 m side-to-side (26-98 ft), eave height 2.5-4 m are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the octagonal tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
