The polygon high peak tent combines a clear-span frame with repeated high peaks for a dramatic, tent-like roofline. It delivers pillar-free volume with the visual character of classic peak marquees.
Our polygon high peak tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Span 10–40 m widths with a repeated high-peak roof on an aluminum clear-span frame.
- Set bay spacing of 3–5 m and eave heights from 2.5 m to 4 m.
- Clad peaks and valleys in PVC with translucent panels for daylight.
- Add gable glass, rolling doors, and window walls for access and light.
- Link multiple bays into long, column-free halls for large crowds.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–40 m width (33–131 ft), multi-peak |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Weddings and gala dinners.
- Trade shows and product launches.
- Festival main stages and VIP areas.
- Corporate and civic events.
Related Products
Polygon High Peak Tent — Frequently Asked Questions
What span widths are available for the polygon high peak tent?
Clear spans from 3 m up to 10–40 m width (33–131 ft), multi-peak are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the polygon high peak tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
