Module Monoridge Tent
The module monoridge tent is a flexible event structure defined by its distinctive single-ridge roof line, letting you join multiple bays into long halls or compact pavilions. Its modular bay system makes it ideal for exhibitions, trade shows and weddings that need a clean, scalable footprint.
Product Overview
- Single-ridge roof line for a clean, architectural profile
- Modular bays clip together into any length or footprint
- Clear-span interior free of poles for open floor planning
- Glass wall, ABS wall and lining options available
- Reusable frame rated for repeated touring use
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–30 m (33–98 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Exhibitions and trade shows
- Weddings and banquets
- Corporate and brand events
- Temporary retail and showrooms
Related Products
Module Monoridge Tent — Frequently Asked Questions
What span widths are available for the module monoridge tent?
Clear spans from 3 m up to large widths are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the module monoridge tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
