Hexadecagon Tent
The hexadecagon tent is our widest polygon structure — sixteen straight sides under a single crown — built to seat huge crowds under one open, column-free roof.
Our hexadecagon tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Build 20–50 m sixteen-sided footprints with a fully open interior floor.
- Raise a central high-peak crown for dramatic height and clear sightlines.
- Extend the polygon in 3–5 m bays to scale from gala to stadium scale.
- Dress walls in PVC, glass, or ABS and add linings for a finished interior.
- Withstand 80–100 km/h wind and 75 kg/m² snow on a 6061/T6 frame.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 20–50 m diameter footprint (66–164 ft), 16-sided polygon |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Large-scale exhibitions and trade halls
- Concerts, sports finals, and ceremonies
- National festivals and civic events
- Permanent-style community and sports centers
Related Products
Hexadecagon Tent — Frequently Asked Questions
What span widths are available for the hexadecagon tent?
Clear spans from 3 m up to 20–50 m diameter footprint (66–164 ft), 16-sided polygon are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the hexadecagon tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
