Crystal Dome House
The Crystal Dome House wraps a geodesic aluminum frame in full-height glass panels, delivering a bright, energy-efficient round living or display space.
Our crystal dome house uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Build a 6-30 m glass dome on an anodized 6061/T6 aluminum geodesic frame.
- Glaze with tempered insulated glass or pair glass with 850 g/m2 PVC roof sectors.
- Seal every node with galvanized connectors tested to 80-100 km/h wind.
- Support 75 kg/m2 snow and wide temperature range for four-season use.
- Fit doors, windows, and HVAC for homes, offices, or retail.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | Diameter 6-30 m (20-98 ft), full glass panel option |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Backyard garden offices and studios.
- Glamping suites and eco-resort rooms.
- Car showrooms and product display pods.
- Spa, hot-tub, and wellness enclosures.
Related Products
Crystal Dome House — Frequently Asked Questions
What span widths are available for the crystal dome house?
Clear spans from 3 m up to Diameter 6-30 m (20-98 ft), full glass panel option are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the crystal dome house be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
