Carport Tent
The carport tent is a low-profile clear-span shelter that shields cars, vans, and boats from sun, rain, and hail without a permanent foundation.
Our carport tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Span 6–12 m to cover 2–6 vehicles or a single boat or motorhome.
- Use 650 g/m² PVC sidewalls or leave open for drive-through access.
- Anchor with ballast, stakes, or leg plates on any flat surface.
- Hold 80–100 km/h wind and 75 kg/m² snow on an anodized aluminum frame.
- Deploy in a day and relocate as a seasonal or rental shelter.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 6–12 m width (20–39 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Home driveway and fleet parking
- Boat, RV, and motorhome storage
- Worksite vehicle and tool cover
- Event staff and shuttle parking
Related Products
Carport Tent — Frequently Asked Questions
What span widths are available for the carport tent?
Clear spans from 3 m up to 6–12 m width (20–39 ft) are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the carport tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
