Arcum Pastoral Marquees
Arcum pastoral marquees bring a soft curved roofline to outdoor celebrations, blending a traditional marquee feel with a modern pole-free aluminum frame.
Our arcum pastoral marquees uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Cover 10–40 m clear spans for 50–1,000 guests with no interior poles.
- Choose ivory, white, or translucent PVC roofs to set the light and mood.
- Drop eave heights of 2.5–4 m and add window walls for an airy, open feel.
- Link bays at 3–5 m pitches so the marquee follows your lawn or courtyard.
- Meet DIN4102 B1 fire codes with 850 g/m² blackout-capable roof covers.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–40 m width (33–131 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Garden weddings and civil ceremonies
- Village fêtes and charity galas
- Estate open days and country shows
- Private parties and milestone celebrations
Related Products
Arcum Pastoral Marquees — Frequently Asked Questions
What span widths are available for the arcum pastoral marquees?
Clear spans from 3 m up to 10–40 m width (33–131 ft) are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the arcum pastoral marquees be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
