Half Dome Double Decker Tent
The half dome double decker tent sets a semicircular crowned roof over a two-level clear-span base, giving an instantly recognizable silhouette with double floor capacity. It works as a landmark pavilion on tight or prominent sites.
Our half dome double decker tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Mount a half-dome aluminum crown on a 10–25 m two-storey clear-span frame.
- Use the ground floor for entrance and service, upper floor for dining or viewing.
- Shape the crown in solid PVC or transparent panels with a vented apex.
- Clad the circular gable ends in glass or graphic PVC for branding.
- Fit stairs, lifts, and terraces to move guests safely between levels.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 10–25 m base width (33–82 ft), 2 floors + half-dome crown |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Landmark brand pavilions at expos.
- VIP hospitality at concerts and sports finals.
- Panoramic restaurants and sky-lounges.
- Ceremonial stages and award venues.
Related Products
Half Dome Double Decker Tent — Frequently Asked Questions
What span widths are available for the half dome double decker tent?
Clear spans from 3 m up to 10–25 m base width (33–82 ft), 2 floors + half-dome crown are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the half dome double decker tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
