Aluminum Foldable Tent
The aluminum foldable tent is a lightweight, scissor-frame canopy that folds to a single case and pops up for markets, stalls, and quick shade anywhere.
Our aluminum foldable tent uses a hard-pressed aluminum clear-span frame with no interior poles, so the full floor area stays open for storage, events, or production. Each unit is built to order with PVC covers, galvanized connectors, and the load ratings shown in the specification table below.
Product Overview
- Open 3–10 m clear spans in under 10 minutes with a two-person scissor frame.
- Weigh 30–60% less than steel using 6061/T6 anodized aluminum legs.
- Pack the whole unit into one wheeled case for car-boot transport.
- Clip 650 g/m² sidewalls, counters, and branding to the eave rail in seconds.
- Stay stable to 60–80 km/h with sandbag or stake foot options.
Technical Specifications
| Parameter | Specification |
|---|---|
| Span width | 3–10 m width (10–33 ft) |
| Frame | Hard-pressed extruded aluminum alloy 6061/T6, anodized |
| Roof cover | 850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optional |
| Sidewall | 650 g/m² (19 oz/yd²) PVC-coated polyester |
| Connectors | Hot-dip galvanized steel, anti-corrosion |
| Wind load | 80–100 km/h (50–62 mph), 0.4–0.5 kN/m² |
| Snow load | 75 kg/m² (15 psf) |
| Temperature | -30 °C to +70 °C |
| Fire resistance | DIN4102 B1 / NFPA 701 / BS 7837 flame retardant |
| Certifications | CE, SGS, ISO 9001, TÜV |
| MOQ | 1 set (mixed containers accepted) |
| Lead time | 15–25 working days |
| Trade terms | FOB Shenzhen / Guangzhou, China |
Typical Applications
- Markets, fairs, and roadside stalls
- Event entrance and ticketing booths
- Camping and tailgate shade
- Promotional sampling and demos
Related Products
Aluminum Foldable Tent — Frequently Asked Questions
What span widths are available for the aluminum foldable tent?
Clear spans from 3 m up to 3–10 m width (10–33 ft) are available, with bay spacing of 3–5 m and eave heights from 2.5 m to 4 m to fit most sites.
How long is the lead time and what are the trade terms?
Standard lead time is 15–25 working days, 1 set (mixed containers accepted), FOB Shenzhen / Guangzhou, China. Mixed containers are accepted.
Can the aluminum foldable tent be customized with glass walls or HVAC?
Yes — options include glass walls, transparent roofs, lining, flooring, lighting truss, and climate control to match the site and intended use.
