No matter outside party or a private garden party, our 30M Arcum Structure Tent will be a good option for you. Especially, popularly used for 200 people small parties. Arcum Structure tent is an update for the A-shape tent with an elegant arch roof.
Our Arcum Structure Tent is made of aluminum framework and steel connections. The size of the tent can be customized. Big Arcum tent can accommodate 500 people. With full accessories, it can be used as a functional event center.
This is the technical data for a 30m Arcum Structure Tent with 6m side height:
Accessories for Arcum Structure Tent
- Flooring system
- Rain gutter
- A glass wall with glass door/ABS wall with glass door
- PVC fabric sidewalls with clear windows
- Lighting system
- Air Condition system
It is easy to set up. The mainframe structure can be assembled within 1 day. There is no pole inside, 100% space is available. If you do not need it anymore, we can do the recycling. The price is attractive, if you have any needs, please feel free to contact us.
Tent Booking
If you want to use this tent during the seasonal high season, then it is recommended to book with us two weeks to six weeks in advance. The basic sizes are 10*15, 10*20, 10*30, 20*40. Providing existing sizes will definitely lead to faster delivery than ordering. Larger or smaller sizes really need to be ordered in advance. We will provide you with installation, maintenance, dismantling, cleaning, storage, and transportation under contract.
This tent can be rented. The price of a used Arcum Structure tent depends on the type, size, and accessories you need. New or old we serve as always. You can shop with confidence.
Technical Specifications
- Frame: 6061-T6 aluminum alloy, 3–4mm wall thickness, 20–30 year lifespan
- Roof & walls: 850gsm double PVC-coated polyester — 100% waterproof, UV & tear resistant, self-cleaning
- Fire rating: flame-retardant to DIN4102 B1 / M2 / CFM
- Connectors: hot-dip galvanized steel
- Wind load: up to 100 km/h (with proper anchoring)
- Snow load: 75 kg/sqm
- Clear-span width: 3–60m, no interior poles or beams (100% usable space)
- Bay distance: 3m / 5m, extendable in modular sections
- Certifications: CE, TÜV, ISO9001, SGS
- Options: glass / ABS / transparent walls, glass doors, flooring, lining, air conditioning, lighting
Tent Size & Capacity Guide
Use this quick reference to match guest numbers to a recommended clear-span size (banquet/seated layouts; theatre or standing fits more):
| Guests | Recommended Size (m) | Imperial (ft) | Floor Area |
|---|---|---|---|
| 100 | 10m × 15m | 33ft × 49ft | 150 m² |
| 150 | 10m × 20m | 33ft × 66ft | 200 m² |
| 200 | 10m × 25m | 33ft × 82ft | 250 m² |
| 300 | 15m × 25m | 49ft × 82ft | 375 m² |
| 500 | 20m × 30m | 66ft × 98ft | 600 m² |
| 800 | 20m × 40m | 66ft × 131ft | 800 m² |
| 1000 | 25m × 40m | 82ft × 131ft | 1000 m² |
| 2000 | 30m × 60m | 98ft × 197ft | 1800 m² |
Frequently Asked Questions
What sizes are available for this arcum arc-roof tent?
This arcum arc-roof tent is built as a clear-span structure available from 3m to 60m wide and extendable in modular bays to any length, so it can be tailored to your exact guest count and site.
What materials is the tent made of?
A 6061-T6 aluminum alloy frame with an 850gsm double PVC-coated cover — 100% waterproof, flame-retardant to DIN4102 B1, wind-rated to 100 km/h and built to last 20+ years.
What are the MOQ, lead time and shipping for this arcum arc-roof tent?
Production typically takes 3–6 weeks depending on size and options. We ship worldwide FOB by container, support flexible MOQ, and provide installation drawings and on-site guidance. Contact us for a quote.
