Custom Arcum Tents: The Ideal Outdoor Temporary Store Solution
Looking to create a unique and functional retail space outdoors? Our custom Arcum Tents offer the perfect solution for temporary stores, pop-up shops, and brand activations, combining elegant design with robust performance.
Arcum Design: Practicality Meets Aesthetics
This project features a distinct arcum roof design. This shape not only looks modern but also significantly improves functionality. The curved structure efficiently disperses wind loads, boosting the tent’s wind resistance and ensuring stability in varied weather.
The tent is covered with striking khaki or sand-colored PVC fabric. This high-quality material offers excellent sun protection and heat insulation, reflecting sunlight to reduce heat buildup inside. This creates a comfortable, cool shopping environment all day long for customers, even during hot summers.
Spacious Interior & Smart Details: An All-Weather Retail Venue
For a pop-up retail space, expansive interior space and well-considered details are crucial. Our custom Arcum Tent uses a clear span design, meaning there are no internal pillars. This maximizes usable space, providing a flexible area for merchandise displays and customer flow. It’s an ideal clear span tent for any retail setup.
To ensure long-term use, we focus on practical details. The tent’s door and window systems are made from custom coffee-colored aluminum alloy, offering both durability and security. The coffee-colored aluminum resists corrosion and provides good sealing, blocking wind, rain, and dust. At the main entrance, a 3-meter extended overhang was designed. This feature effectively blocks direct sunlight for shade and shields from rain, ensuring the store can be used year-round, all day long, regardless of weather. This makes it an excellent choice for any outdoor event tent application.
Your Professional Retail Space Solution
This custom Arcum Tent project demonstrates our ability to deliver high-performance, customizable space solutions for retail. If you need a practical, functional, temporary, or semi-permanent structure, our team can help. We’ll customize an Arcum tent solution based on your site, budget, and specific needs. Project investment depends on factors like tent size, structural materials, fabric grade, and custom additions. We provide detailed cost breakdowns for clarity.
Technical Specifications
- Frame: 6061-T6 aluminum alloy, 3–4mm wall thickness, 20–30 year lifespan
- Roof & walls: 850gsm double PVC-coated polyester — 100% waterproof, UV & tear resistant, self-cleaning
- Fire rating: flame-retardant to DIN4102 B1 / M2 / CFM
- Connectors: hot-dip galvanized steel
- Wind load: up to 100 km/h (with proper anchoring)
- Snow load: 75 kg/sqm
- Clear-span width: 3–60m, no interior poles or beams (100% usable space)
- Bay distance: 3m / 5m, extendable in modular sections
- Certifications: CE, TÜV, ISO9001, SGS
- Options: glass / ABS / transparent walls, glass doors, flooring, lining, air conditioning, lighting
Tent Size & Capacity Guide
Use this quick reference to match guest numbers to a recommended clear-span size (banquet/seated layouts; theatre or standing fits more):
| Guests | Recommended Size (m) | Imperial (ft) | Floor Area |
|---|---|---|---|
| 100 | 10m × 15m | 33ft × 49ft | 150 m² |
| 150 | 10m × 20m | 33ft × 66ft | 200 m² |
| 200 | 10m × 25m | 33ft × 82ft | 250 m² |
| 300 | 15m × 25m | 49ft × 82ft | 375 m² |
| 500 | 20m × 30m | 66ft × 98ft | 600 m² |
| 800 | 20m × 40m | 66ft × 131ft | 800 m² |
| 1000 | 25m × 40m | 82ft × 131ft | 1000 m² |
| 2000 | 30m × 60m | 98ft × 197ft | 1800 m² |
Frequently Asked Questions
What sizes are available for this arcum arc-roof tent?
This arcum arc-roof tent is built as a clear-span structure available from 3m to 60m wide and extendable in modular bays to any length, so it can be tailored to your exact guest count and site.
What materials is the tent made of?
A 6061-T6 aluminum alloy frame with an 850gsm double PVC-coated cover — 100% waterproof, flame-retardant to DIN4102 B1, wind-rated to 100 km/h and built to last 20+ years.
What are the MOQ, lead time and shipping for this arcum arc-roof tent?
Production typically takes 3–6 weeks depending on size and options. We ship worldwide FOB by container, support flexible MOQ, and provide installation drawings and on-site guidance. Contact us for a quote.
