Polygon Huge Hall
Polygon Huge Hall The polygon huge hall is our largest clear-span solution for mass-gathering events, industrial shelters and sports arenas. Multi-sided geometry maximizes interior volume and sightlines while the aluminum frame delivers fast, reusable deployment at scale. Product Overview Largest clear spans in our range, no interior columnsMulti-sided geometry for maximum volume and sightlinesEngineered for high wind and snow loadsModular bays for very long or wide footprintsIndustrial and event-grade lining options Technical Specifications ParameterSpecificationSpan width30–80 m (98–262 ft)FrameHard-pressed extruded aluminum alloy 6061/T6, anodizedRoof cover850 g/m² (25 oz/yd²) PVC-coated polyester, UV-resistant, blackout optionalSidewall650 g/m² (19 oz/yd²) PVC-coated polyesterConnectorsHot-dip galvanized steel, anti-corrosionWind load80–100 km/h (50–62 mph), 0.4–0.5 kN/m²Snow load75 kg/m² (15 psf)Temperature-30 °C to +70 °CFire resistanceDIN4102 B1 / NFPA 701 / BS 7837 flame retardantCertificationsCE, SGS, ISO 9001, TÜVMOQ1 set (mixed…
