If you’d like to celebrate a business get-together or possibly a non-public family celebration within the budget, then creating an event structure is regarded to be the cost-effective and artistic solution to make.
One particular unique type of a strong event structure is the geodesic dome tent that appears to have a roundish layout, developing a creatively attractive fabric edifice. Yet it’s not only that. Utilizing this type of special function, the structure proficiently sheds off the snow during an extreme blizzard in winter, protecting the temporary building from collapsing because of snow pile-up.
This is a unique and powerful movable structure type geodesic dome tent. Creative and attractive behemoth. It’s like a giant ping pong ball lying on the ground. In extreme winter storms, the dome can easily slide off the snow. The rigidity of the triangular bracket is the best partner for the dome.
The excellent geodesic dome structure can withstand greater wind resistance than other tents. At the same time, it uses less base steel, making it an extremely environmentally friendly tent.
The range of application of the geodesic dome tent is extremely wide. 15m in diameter or less is very suitable as a single room in the hotel tent. The largest size of 80m geodesic dome tent can be used for various large conferences, exhibition centers, and even specialty restaurants.
Please be free to contact us for more information.
Technical Specifications
- Frame: 6061-T6 aluminum alloy, 3–4mm wall thickness, 20–30 year lifespan
- Roof & walls: 850gsm double PVC-coated polyester — 100% waterproof, UV & tear resistant, self-cleaning
- Fire rating: flame-retardant to DIN4102 B1 / M2 / CFM
- Connectors: hot-dip galvanized steel
- Wind load: up to 100 km/h (with proper anchoring)
- Snow load: 75 kg/sqm
- Clear-span width: 3–60m, no interior poles or beams (100% usable space)
- Bay distance: 3m / 5m, extendable in modular sections
- Certifications: CE, TÜV, ISO9001, SGS
- Options: glass / ABS / transparent walls, glass doors, flooring, lining, air conditioning, lighting
Tent Size & Capacity Guide
Use this quick reference to match guest numbers to a recommended clear-span size (banquet/seated layouts; theatre or standing fits more):
| Guests | Recommended Size (m) | Imperial (ft) | Floor Area |
|---|---|---|---|
| 100 | 10m × 15m | 33ft × 49ft | 150 m² |
| 150 | 10m × 20m | 33ft × 66ft | 200 m² |
| 200 | 10m × 25m | 33ft × 82ft | 250 m² |
| 300 | 15m × 25m | 49ft × 82ft | 375 m² |
| 500 | 20m × 30m | 66ft × 98ft | 600 m² |
| 800 | 20m × 40m | 66ft × 131ft | 800 m² |
| 1000 | 25m × 40m | 82ft × 131ft | 1000 m² |
| 2000 | 30m × 60m | 98ft × 197ft | 1800 m² |
Frequently Asked Questions
What sizes are available for this geodesic dome?
This geodesic dome is built as a clear-span structure available from 3m to 60m wide and extendable in modular bays to any length, so it can be tailored to your exact guest count and site.
What materials is the tent made of?
A 6061-T6 aluminum alloy frame with an 850gsm double PVC-coated cover — 100% waterproof, flame-retardant to DIN4102 B1, wind-rated to 100 km/h and built to last 20+ years.
What are the MOQ, lead time and shipping for this geodesic dome?
Production typically takes 3–6 weeks depending on size and options. We ship worldwide FOB by container, support flexible MOQ, and provide installation drawings and on-site guidance. Contact us for a quote.
