Arcum Tent Series includes ABT(15-25m, main profile: 204x120x4mm), AEBT(15-30m, main profile: 256x120x5mm), ATH (15-40m, main profile 300x125x5/8mm), it’s modular structure, whose length can be increased and decreased by 5m bay. High reinforced aluminum alloy (6061/T6) is used for the frame of the arcum tent, and fire retardant double-side PVC synthetic fabric is adapted for roof covers, which conform to European DIN4102 B1, M2 standard.
Arcum Event Tent Dimensions
|Span Whidth||Eave Height||Ridge Height||Bay Distance||Main Profile|
|15m||3.92m||5.4m||5m||300x120x5mm (4 - channel)|
|20m||3.92m||6.3m||5m||300x120x5mm (4 - channel)|
|25m||3.92m||7.15m||5m||300x120x5mm (4 - channel)|
|30m||3.92m||7.87m||5m||300x120x5mm (4 - channel)|
|40m||3.92m||9.6m||5m||300x120x5mm (4 - channel)|
