Polygon Structure Tent

Category: Tag:

A polygon structure tent is evolved from an A-frame structure tent. With its soft appearance and stable structure, it is one of the top sales tent series in the market. It is suitable for large-scale storage, concerts, exhibitions, company activities, and temporary, semi-permanent, or permanent construction purposes.

Standard clear span sizes: 10m, 12m, 15m, 18m, 20m, 25m, 30m-60m, the modular bay section is 5m. The length can be extended in multiples of 5m without restriction.

The frame of the polygon structure tent is made up of reinforced aluminum alloy T6 extrusions, which is not easy to get rust and can be disassembled quickly. The eave height can be 5m.

The fabric adopts double PVC coated polyester textile, which has the characteristics of high heat resistance, UV resistant, fire retardant under standard B1, and surface self-cleaning.

Customized design and manufacturing are available.

  • Optional Accessories
  • Clear windows PVC sidewalls
  • Ground anchor
  • Weight plate
  • Decorative roof lining and sidewalls curtains
  • Double wing glass door
  • Mandoor
  • Transparent roof covers and sidewalls, ABS solid walls
  • Flooring system
  • Rain gutter

Product Specification

Span WhidthEave HeightRidge HeightBay DistanceMain Profile
10m4m7.16m5m204x120x4mm (4 - channel)
15m4m8.75m5m204x120x4mm (4 - channel)
18m4m9.15m5m204x120x4mm (4 - channel)
20m4m9.42m5m204x120x4mm (4 - channel)
25m4m11.72m5m256x121x5mm (4 - channel)
30m4m13.2m5m256x121x5mm (4 - channel)
40m4m15.4m5m300x120x5mm (4 - channel)
50m4m16m5m300x120x5mm (4 - channel)
60m4m17m5m400x120x7mm (4 - channel)
