Arcum Dome Tent Specifications:
1 Shape: Arcum or Dome
2 Mian profile size: 2014x120x4mm(4 -channel)
3 Wind loading: 100km/h
Minimum tent length: In order to reach the designed wind load and make sure the tent is safe, pls set up the tent with the required minimum tent length
For more details, please refer to the following charts.
| Model No. | Shape | Span Width | Length | Bay Distance | Eave Height | Ridge Height |
| ABT15 | Arcum | 15m | unlimited | 5m | 4m | 5.73m |
| ABT20 | Arcum | 20m | unlimited | 5m | 4m | 6.53m |
| ABT25 | Arcum | 25m | unlimited | 5m | 4m | 7.33m |
| Model No. | Shape | Span Width | Length | Bay Distance | Eave Height | Ridge Height |
| DBT10 | Dome | 10m | unlimited | 5m | 4m | 4.94m |
| DBT15 | Dome | 15m | unlimited | 5m | 4m | 5.73m |
| DBT20 | Dome | 20m | unlimited | 5m | 4m | 6.53m |
| DBT25 | Dome | 25m | unlimited | 5m | 4m | 7.33m |
2. Optional Accessories,
-Clear PVC Window Sidewall
-Glass Wall
-ABS Wall
-Lining and Curtain
-Doors
-Flooring System
-Ground Anchor
-Lighting
-Anchor Puller
-Weight Plate
-Ramp
-Transport Rack
……………
……………
3.Materials:
1) Frame uses hard pressed extruded aluminium 6061/T6(13HW).
2) The fabric is double PVC-coated polyester textile. It is high quality at waterproof, flame retardant to DIN4102 B1, M2, UV resistant, waterproof.
4. Life span:
Fabric (cover & sidewalls): 10years if well maintained.
Aluminum frame and galvanized connectors: 20years if well maintained.
5. Color available:
White, red, yellow, blue, green, black, grey, transparent etc
6. Installation of tents, canopies and marquee tents:
We will provide you the installation manual in English and Russian. Supervisor will be available if needed.
7. Fixing Methods
1) Expandable Bolt, used in the concrete ground
2) Ground Anchor, used all kinds of soft ground, such as earth, sandy
3) Weight Plate, it is the best choice for you who runs the rental business, used in all kinds of ground, expecially for the indestructible ground.
8. Package of Liri Tents, Canopies and Marquee tents
1) Aluminum Frame–membrane film
2)Hardware–solid carton box
3) Tent cover–PVC carry bag.
9. Certificates
1) Germany TUV Certificate, SGS, ISO9001: 2008
2) Qualification from Australia
3) Qualification from USA
4) Advanced design and Quality proved
5) Fabric: Test reports for the fire retardant, standards: NFPA701, CFM & DIN4102 B1/M2
6) Structure safety: Certificates by the registered engineers in the U. S. A & Australia.
If the customers need above certificates copy, pls feel free to contact with Liri Tent Technology. We will not show them on the website to avoid copys.
10. Superiority of tents
1 Sizes can be customized
2 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
3 No pole inside, 100% room is available
4 Trouble-free and easy transportation, erection, dismantling, storage
5 Wind loading up from 80 to 100 km per hour
6 Multifunctional, widely used for different request
Company Information
Liri Tent Technology (Zhuhai) Co., Ltd. was established in 1997. Our company is the first professional manufacturer who introduced European advanced tents technology into our own design. Our main products include Modular Aluminium Alloy Structure Tents, Clear Span Tent Structure and Aluminium Alloy Square Pagoda & Summer Gazebo.
To form an integrated management system,Liri Tent introduced advanced ERP system in 2008 and bar code management system in 2013. Liri Tent is also the pioneer to apply CNC machines that achieved the automatic processing of aluminum.
Reputation
1) The first tent manufacturer established in 1997 in China.
2) The largest tent manufacturer in China which covers 100, 000sqm and including 50, 000sqm building area.
3) The most reliable tent supplier. Exported to over 97 countries, and maintaining excellent reputation,
4) The NO. 1 tent exporter for years in China.
5) Engieer’s Company, the owner of Liri Tent is more concern quality and safety than you.
LIRI TENT Successful Cases:
Kinds of New Style Tent for China Open
Canton Fair Exhibition Hall
2011 Universiade Official Tent Supplier
2010 Asian Games Exclusive Tent Supplier&Sponsor
Dior Event in Hong Kong
China Grand Rally Sponsor
Hong Kong Wine and Dine Festival
FAQ
Q1: Can you print our logos on tent?
Yes.Customized logos can be print on the tent fabric according to your requirements.
Q2: Is that factory price?
Yes. We assure you all prices are based on factory.
Q3: Does your tent be able to install repeatedly?
Our tents can be assembled and dismantled repeatedly with small transportation size.The lifespan of aluminium framework can reach 15-20 years,and 5-8 years for PVC fabrics depending on different conditions of usage.
Q4: What documents are available?
A full range documents including structural drawings,packing list,installation manual and relative certificates can be provided.Moreover,customs declaration is provided.We provide one-stop service for you.
Q5: What size tent is necessary for your special event?
A person must first determine tent usage. If a tent is being used for dining purposes and round tables are being used allow 10-12 square feet per person. If banquet style tables are being used allow 8-10 square feet per person.If the purpose is for cocktail service allow five to six square feet per person. Contact us for all your specific questions and more information on tent types.
Q6: Has your tent product been certified?
Yes.Our tent product has passed the engineering tests and gained the America And Australia structural engineering certificates. Besides, the PVC fabric used for roof covers and sidewalls has passed the fire tests and gained the flame retardant certificates issued by America, Australia, New Zealand, and Britain.
Q7: Is your tent strong and stable enough? How about the wind loading?
Yes.The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6) so our tent structure is safe and strong and can resist wind up to 100 km/hr.
Q8: How long is the warranty period?
Guarantee one year. During the warranty period, we shall repair or replace the damaged part accordingly because of any damage due to quality problem.
